DIMLUX - XPLORE SERIES LED | 800W - 2283 µmol/s - 2.85 µmol/J

Dimlux Xplore 800W Series: High-end LED lighting affordable for every grower
Dimlux has made a breakthrough with the introduction of the Xplore Series, making high quality LED lighting now a reality for every grower. This new series embodies the uncompromising quality for which Dimlux is known, but at an affordable price.

High output through exceptional performance
With a significant R&D effort, Dimlux has developed the Xplore Series, achieving an exceptional combination of performance and light distribution that is unrivalled in its class. With a total efficiency of up to 2.85 µmol/J and a light output of up to 2283 µmol/s, the Xplore 800W Series devices deliver impressive performance, ensuring maximum output with minimum energy consumption.

Uniform light distribution through asymmetrically positioned LEDs
One of the features that make the Xplore Series unique is the asymmetric positioning of the LED diodes, ensuring even light distribution over the entire growing area, with the edges receiving up to 80% more light than normally positioned LEDs. This ensures uniform growth and flowering, allowing your crops to flourish optimally under the powerful Dimlux light.

Future-ready and upgradeable
But it doesn't stop at performance alone. Dimlux guarantees the durability of its products, offering a convenient 3-year guarantee*. In addition, the Xplore Series offers numerous expansion options, including optional UV and far-red add-ons to expand the colour spectrum, as well as the ability to add the Dimlux Maxicontroller for complete control of growing conditions.

Return on investment
With an affordable entry price, the Dimlux Xplore Series is an investment that pays for itself, putting high-quality LED lighting within reach. Choose the Dimlux Xplore Series 800W and let your crops thrive under reliable light.

Warranty terms apply. See product specifications for details.

Benefits at a glance:

• Total photon efficiency 800W: 2.85 µmol/J
• Total Light Output (PPF) 800W: 2283 µmol/s
• Unrivalled light distribution thanks to asymmetrically positioned LED diodes
• Future-ready luminaire
• 3-year Dimlux guarantee*.
• Options for the ambitious grower to develop an optimal set-up
• Optional expansion with UV and far-red add-ons to expand the light spectrum
• Optional expansion with the Dimlux Maxicontroller for complete control
• Affordable price

• Xplore 800W LED luminaire including driver and dimmer
• Power cable
• Pulley suspension system
• User's manual

Technical specifications Xplore 800W

• Dimensions: 1105x1067x54mm / 43.5x42.0x2.1 inches
• Light source: 800W LED
• Driver: 800W Dimlux Xplore digital driver
• Spectrum: Full spectrum red and white LED diodes
• Light output (PPF): 2231 µmol/s
• Total light output (PPF 350-800nm): 2283 µmol/s
• PAR photon efficiency (400-700nm): 2.80 µmol/J @ 230-240V AC
• Total photon efficiency (350-800nm): 2.85 µmol/J @ 230-240V AC
• AC input power: 800W @ 230-240V AC
• AC input voltage: 200-277V AC, 50/60Hz
• Beam angle: 120°
• Optics: Conformal Coating
• Recommended mounting height: 150×150cm min. 40cm / 5'×5' min. 1.35'
• Recommended mounting height: 120×120cm min. 30cm / 4'×4' min. 1'
• LED positioning: Asymmetrical
• Ambient temperature: -25 ~ 40°C / -13 ~ 105°F
• Control: Via Dim button or 0-10V Controller
• Total Harmonic Distortion (THD): < 10%.
• Service life L90: > 50,000 hours
• IP rating: IP44
• Certifications: ETL, CE, UKCA
• Weight: 10.60kg / 23.32 lbs
• Warranty: the first 2 years are covered by full warranty.
