THINKGROW - SMART LIGHT LIFTER LLT-2 AUTOMATIC LAMP LIFTER SYSTEM

he ThinkGrow Smart Light Lifter (LLT-2) with RC-1 lifting cable kit is an advanced automatic lifting system designed for professional farming and indoor cultivation.
It automatically raises and lowers additional grow lights, sensors and other equipment, ensuring precise height management during all phases of plant growth.

Compact, silent and easy to install, the LLT-2 ensures precision, synchronisation and ease of use. Each unit can lift loads of up to 60 kg with a maximum stroke of 2.8 metres, making it ideal for large, professional plants.

The lifters can be linked together thanks to the automatic alignment function and are compatible with both the Smart Lifter Remote and the TrolMaster Hydro-X Pro control system, allowing for full integration into advanced automation systems.

Key features

• Automatic lifting and lowering of grow lights

• Lifting capacity up to 60 kg per unit

• Maximum stroke of 2.8 m

• Compact and silent design

• Quick and easy installation

• Possibility to connect several lifters with automatic alignment

• Compatible with Smart Lifter Remote LRC-1

• Integration with TrolMaster Hydro-X Pro for advanced control

• Ideal for lamps, sensors and cultivation equipment

Technical Specifications

• Input voltage: 110-240 V AC, 50/60 Hz

• Power consumption: ≤ 165 W

• Lifting range: ≤ 2.8 m (9.2 ft)

• Maximum liftable weight: ≤ 60 kg (132 lb)

• Working temperature: 0-40 °C (32-104 °F)

• Working humidity: ≤ 90 % RH

• Packaging dimensions: 375 × 245 × 136 mm

• Gross weight: 5 kg

Package Contents

• 1 × ThinkGrow Smart Light Lifter (LLT-2)

• 1 × Power cable

• 1 × Signal Cable

• 1 × RC-1 lifting cable kit

Advantages

• Automatic and precise lamp height adjustment

• Improves light uniformity and plant health

• Reduces manual intervention and handling time

• Seamless integration with professional automation systems

• Ideal for grow rooms, greenhouses and advanced indoor facilities
